Overview & Specifications
Overview & Specifications
Your XO outdoor rated Refrigerated Drawer unit has two locking drawers capable of holding up to 108 (12oz) cans from 50 degrees down to a frosty 34 degrees F. Designed to install under counter with fingerprint resistant stainless steel finish and choice of two handle styles included.
If you're looking for a convenient way to store your food and beverages outdoors at the perfect temperature, the XO Outdoor Refrigerated Drawer is just what you need. This innovative appliance is designed to fit seamlessly into your kitchen, giving you easy access to cold drinks, fresh produce, and anything else you might need at a moment's notice.
STANDOUT FEATURES- 5.2 Cu. Ft. Capacity Stores (132) 12-Oz Cans
- Bottom Drawer can hold bottles up to 12 1/8" tall
- Outdoor Rated
- Smooth Glide Drawers easy open and close
- Secure Drawer Lock Included
- Customizable Drawer Divider
- Tri-color LED interior lighting
- Intuitive digital temperature control adjusts from 34 to 50 F
- Energy-efficient- Estar Rated
- Quiet Operation 39 dBA
- Two Handle Styles Included
- Drawer ajar and Temp Alarm ensure your contents are safe
- Fingerprint-Resistant Stainless Steel Exterior
- Flush installation design
- X- Active Fan-assisted cooling system allows for even temperatures, quicker cooldown times, and added efficiency
Origin | China |
UPC | 814830013570 |
Height | 34 1/8" |
Width | 23 7/8" |
Depth | 23 3/8" |
Cut-Out Depth (in.) | 24" |
Cut-Out Height (in.) | 34 1/4" |
Cut-Out Width (in.) | 24" |
Depth (Excluding Handles) | 23 3/8" |
Depth (Including Handles) | 25 1/8" |
Depth (Less Door) | 21 13/16" |
Depth With Door Open 90 Degrees (In) | 38 1/2" |
Dimensions D x W x H | 23 3/8" x 23 7/8" x 34 1/8" |
Product Weight | 160 |
Warranty 1 Explained | 90 Day Love It Or Leave It |
Warranty 2 Explained | 2 year limited parts and labor warranty for the original owner |
Warranty 3 Explained | 5 year limited compressor parts only warranty for the original owner |
ADA Compatible | No |
Certification | CSA |
Prop 65 | Yes |
Freight Class | 92.5 |
Shipping Weight | 160 |
Carton Height | 37" |
Carton Width | 27" |
Carton Depth | 29" |
Shipping Method | LTL |
Amperage | 1.2 amps |
Electrical | 115V-60Hz-1.2 Amps |
Frequency (Hz) | 60Hz |
Voltage (volts) | 115V |
Wattage (watts) | 138 watts |
Ambient Temperature | 60 to 90 degrees F |
Appliance Type | Outdoor refrigerated drawer |
Can Storage Capacity | 132 (12oz) |
Color of Handle | Stainless Steel |
Color/Finish | Fingerprint Resistant Stainless Steel |
Control Type | Intuitive Touch Digital Controls |
Cooling Unit Type | Air Cooled Compressor |
Cubic Foot Capacity | 5 cu ft |
Defrost Type | Automatic Defrost |
Door Features | Soft close Fingerprint Resistant Stainless Steel |
Door Lock | Yes |
Filter Type | Activated carbon air filter |
Install Type | Flush Undercounter |
Installation Type | Flush Undercounter |
Interior Finish Type | White powder coated steel |
Interior Lighting | Tri-Color LED Interior Illumination |
Leveling Legs | Included |
LIght Colors | Midnight Blue, Theater White, Honey Amber |
Light Type | Tri-Color LED Interior Illumination |
Lighting Features | Three lighting modes |
Max Temperature Zone 1 | 50 degrees F |
Min Temperature Zone 1 | 34 degrees F |
Number of Doors | 2 |
Number of Temperature Zones | 1 |
Open Door Alarm | Yes |
Operational Features | Energy Saver Mode |
Power Cord Included | 6' with Flat Plug |
Programmed Features | Power, Lighting & Alarms |
Required Plug Type | 5-15P Plug Type |
Returnable | No |
Sabbath Mode | Yes |
Storage Features | Adjustable drawer divider |
Toe Kick Color | Stainless Steel |
Vent Location | Bottom Front |
Wheels/Casters | No |
Wireless Compatibility | No |
Control Lighting | Backlit LCD |
Controls | Electronic Touch |
Location | Outdoor |
Refrigerant | R600a |
Sound Level | 37 dBA |
