The XOQ is a beautiful combination of flat glass and stainless steel. The minimalist, flat glass canopy extension merges seamlessly with other design elements. Now equipped with our advanced Code Compliance Control.
The XOQ is a striking fusion of Italian stainless steel and glass. The flat surface easily aligns with shelving to provide a visually seamless appearance permitting the XOQ to conform with your design while making its own elegant statement.
STANDOUT FEATURES- Electronic Speed Control + Power Boost
- CCC Code Compliance Control - 395 or 600 CFM*
- High Efficiency 3000k LED Lights (x2)
- Standard Chimney fits ceilings up to 9' tall
- Dishwasher Safe Aluminum Mesh Filter
- 6" Vertical Duct or Recirculating (Kit Sold Separately)
- (Recirculated air must be returned to the living space)
- 5 Minute Delay Shutoff Timer
- Made In Italy
*NOTE: When CCC™ is enabled the number of fan speeds will be reduced to maximum 3 speeds
Collection | Fabriano Collection |
Origin | Italy |
UPC | 814830012948 |
Height | 25 13/16" to 43 11/16" |
Width | 36" |
Depth | 19 5/16" |
Dimensions D x W x H | 19 5/16" x 36" x 25 13/16" to 43 11/16" |
Product Weight | 29 |
Warranty 1 Explained | 90 Day Love It Or Leave It |
Warranty 2 Explained | 2 Year Limited Material And Workmanship for the original owner |
ADA Compatible | No |
Certification | UL |
Prop 65 | Yes |
Freight Class | 85 |
Shipping Weight | 32 |
Carton Height | 28" |
Carton Width | 40" |
Carton Depth | 28" |
Shipping Method | LTL |
Amperage | 3.85 Amps |
Electrical | 120V - 60Hz - 3.85 Amps |
Frequency (Hz) | 60 Hz |
Voltage (volts) | 120 VAC |
Wattage (watts) | 462 watts |
Appliance Type | Range Hoods |
CCC Code Compliance Control | Yes |
CFM @ Speed 1 | 160 |
CFM @ Speed 2 | 250 |
CFM @ Speed 3 | 395 |
CFM @ Speed 4 | 600 |
Color/Finish | Stainless |
Commerical/Residential | Residential |
Control Type | Backlit LED |
Cooktop Lights | Twin LED Lights |
Duct Size | 6" Dia. |
Ductless Convertible | Ducted or Convertible |
Filter Type | Dishwasher Safe Mesh Filters |
Install Type | Wall chimney mount |
Installation Type | Wall chimney mount |
LIght Colors | White |
Light Type | Twin LED Lights |
Lighting Features | 3000K LED |
Maximum Air Flow Capacity CFM) | 600/395 |
Minimum Air Flow Capacity (CFM) | 160 |
Mounting Height Above Cooktop | 27" - 32" |
Number of Light Bulbs | 2 |
Number of Speeds | 4 |
Returnable | No |
Sones @ Speed 1 | 1 |
Sones @ Speed 2 | 2.5 |
Sones @ Speed 3 | 4 |
Sones @ Speed 4 | 6.5 |
Vent Location | Top |
Vent Material | Metal |
Wireless Compatibility | No |
Control Lighting | Blue Backlit |
Controls | Code Compliance Electronic Controls |
Location | Indoor |
Sound Level | 1.0-6.5 Sones |
Assembled Depth (in.) | No |
