The classic architectural lines that have inspired a revolution in modern hood design. Simple yet elegant, a timeless design that will endure in your kitchen for years to come. Now equipped with our advanced Code Compliance Control. Quiet and efficient at an unbelievable price.
The Classic architectural lines that have inspired a revolution in modern hood design. Simple yet elegant, a timeless design that will endure in your kitchen for years to come. Quiet and efficient at an unbelievable price.
STANDOUT FEATURES- Electronic 3 Speed Control + Power Boost
- CCC Code Compliance Control - 395 or 600 CFM*
- High Efficiency 3000K LED lights (x2)
- High Velocity Blower optimally removes Smoke, Grease and Odors
- Dishwasher Safe Aluminum Mesh Filter
- 6" Vertical Duct or Recirculating (Kit Sold Separately)
- 5 Minute Delay Shutoff Timer
- Standard Chimney fits ceilings up to 9' tall
- Made In Italy
*NOTE: When CCC™ is enabled the number of fan speeds will be reduced to maximum 3 speeds
Collection | Fabriano Collection |
Origin | Italy |
UPC | 814830012535 |
Height | 28 3/4" to 44" |
Width | 24" |
Depth | 19 3/8" |
Dimensions D x W x H | 19 3/8" X 24" x 28 3/4" to 44" |
Product Weight | 27 |
Warranty 1 Explained | 90 Day Love It Or Leave It |
Warranty 2 Explained | 2 Year Limited Material And Workmanship for the original owner |
ADA Compatible | No |
Certification | UL |
Prop 65 | Yes |
Freight Class | 85 |
Shipping Weight | 30 |
Carton Height | 28" |
Carton Width | 30" |
Carton Depth | 28" |
Shipping Method | LTL |
Amperage | 3.6 Amps |
Electrical | 120V - 60Hz - 3.6 Amps |
Frequency (Hz) | 60 Hz |
Voltage (volts) | 120 VAC |
Wattage (watts) | 430 watts |
Appliance Type | Range Hoods |
CCC Code Compliance Control | Yes |
CFM @ Speed 1 | 160 |
CFM @ Speed 2 | 250 |
CFM @ Speed 3 | 395 |
CFM @ Speed 4 | 600 |
Color/Finish | Stainless |
Commerical/Residential | Residential |
Control Type | Backlit LED |
Cooktop Lights | Twin LED Lights |
Duct Size | 6" Dia. |
Ductless Convertible | Ducted or Convertible |
Filter Type | Dishwasher Safe Mesh Filters |
Install Type | Wall chimney mount |
Installation Type | Wall chimney mount |
LIght Colors | White |
Light Type | Twin LED Lights |
Lighting Features | 3000K LED |
Maximum Air Flow Capacity CFM) | 600/395 |
Minimum Air Flow Capacity (CFM) | 160 |
Mounting Height Above Cooktop | 27" - 32" |
Number of Light Bulbs | 2 |
Number of Speeds | 4 |
Returnable | No |
Sones @ Speed 1 | 2.5 |
Sones @ Speed 2 | 4 |
Sones @ Speed 3 | 6.5 |
Vent Location | Top |
Vent Material | Metal |
Wireless Compatibility | No |
Control Lighting | Blue Backlit |
Controls | Code Compliance Electronic Controls |
Location | Indoor |
Sound Level | 1.0 - 6.5 Sones |
Assembled Depth (in.) | No |
