Overview & Specifications
Overview & Specifications
Enamelled grates and grates and burner cap
Nothing lasts longer and is easier to clean: enamelled cast-iron grates and burners with PerfectClean.
ComfortClean Dishwasher-Safe Grates
Fast cleaning: Remove the pot rests and wash in the dishwasher. Fast clean-up with dishwasher-safe grates.
DESIGN
Individual design
Attractive design to suit all tastes: a minimalist stainless-steel look or elegant ceramic glass.
USER CONVENIENCE
Single-handed electronic ignition
No need for matches or lighters: automatic ignition of burners thanks to intelligent technology.
Comfort handle with integrated controls with knobs
Easy controls to regulate: Convenient power level control via plastic or metal knobs.
EFFICIENCY AND SUSTAINABILITY
Gas - efficient and environmentally friendly
With environmental and economic benefits: Cooking with gas
SAFETY
GasStop
Reassuring: If the flame is extinguished, for example by a draught, the continued supply of gas is prevented.
FEATURES
Versatile burner configuration
From economical to powerful: There is a suitable burner with the optimum output for every application.
- Enamelled grates and grates and burner cap
- Nothing lasts longer and is easier to clean: enamelled cast-iron grates and burners with PerfectClean.
- ComfortClean Dishwasher-Safe Grates
- Fast cleaning: Remove the pot rests and wash in the dishwasher. Fast clean-up with dishwasher-safe grates.
- Individual design
- Attractive design to suit all tastes: a minimalist stainless-steel look or elegant ceramic glass.
- Single-handed electronic ignition
- No need for matches or lighters: automatic ignition of burners thanks to intelligent technology.
- Comfort handle with integrated controls with knobs
- Easy controls to regulate: Convenient power level control via plastic or metal knobs.
- Gas - efficient and environmentally friendly
- With environmental and economic benefits: Cooking with gas
- GasStop
- Reassuring: If the flame is extinguished, for example by a draught, the continued supply of gas is prevented.
- Versatile burner configuration
- From economical to powerful: There is a suitable burner with the optimum output for every application.
Type of heating | |
Fuel type | Gas |
Construction type | |
Independent of oven | • |
Design | |
Stainless steel trough | • |
Cast iron pot rest (matte black enameled) | • |
Ring features | |
No. of rings | 5 |
1st cooking zone/cooking area | |
Position | front left |
Type | High-speed burner |
Max. rating in W | 2500 |
2nd cooking zone/cooking area | |
Position | rear left |
Type | Economy burner |
Max. rating in W | 1100 |
3rd cooking zone/cooking area | |
Position | Centered |
Type | Single wok burner |
Max. rating in W | 3300 |
4th cooking zone/cooking area | |
Position | rear right |
Type | Standard burner |
Max. rating in W | 1600 |
5th cooking zone/cooking area | |
Position | front right |
Type | Standard burner |
Max. rating in W | 1600 |
Control panel | |
Operation via knobs | • |
Electronic ignition with one-handed operation | • |
Cleaning convenience | |
Dishwasher-save trivets | • |
PerfectClean burner | • |
Safety | |
GasStop | • |
Technical data | |
Width in in. (mm) | 29 5/8 (750) |
Height in in. (mm) | 3 5/8 (90) |
Depth in in. (mm) | 20 1/2 (520) |
Cutout dimensions width in in. (mm) with proud-mounted installation | 22 1/8 (560) |
Cutout dimensions depth in in. (mm) with proud-mounted installation | 19 (480) |
Weight in lbs. (kg) | 35 (16) |
Total connected load in kW | 10.17 |
Voltage in V | 120 |
Frequency in Hz | 60 |
Power cord length in ft. (m) | 3 (1.2) |
