Overview & Specifications
Overview & Specifications
MAINTENANCE
ComfortClean Dishwasher-Safe Grates
Clean Touch Steel™Front
USER CONVENIENCE
Backlit Precision Knobs
SPECIAL FEATURES
Continuous simmer
ComfortClean Dishwasher-Safe Grates
Fast cleaning: Remove the pot rests and wash in the dishwasher. Fast clean-up with dishwasher-safe grates.
Clean Touch Steel™Front
No fingerprints on stainless steel: surface has special finish which keeps clean without special cleaning agents.
USER CONVENIENCE
Backlit Precision Knobs
With QuickStart there's no need to press or hold the control in order to switch the burners on.
SPECIAL FEATURES
Continuous simmer
The perfect temperature and even heat for simmering: Whether you are melting chocolate or thickening a sauce.
- ComfortClean Dishwasher-Safe Grates
- Fast cleaning: Remove the pot rests and wash in the dishwasher. Fast clean-up with dishwasher-safe grates.
- Clean Touch Steel(TM)Front
- No fingerprints on stainless steel: surface has special finish which keeps clean without special cleaning agents.
- Backlit Precision Knobs
- With QuickStart there's no need to press or hold the control in order to switch the burners on.
- Continuous simmer
- The perfect temperature and even heat for simmering: Whether you are melting chocolate or thickening a sauce.
Heating type | |
Fuel type | Gas |
Design | |
Rangetop | • |
Design | |
Casing | Stainless steel |
Front panel | CleanSteel |
Genuine metal knobs | • |
Cast iron pot rests (matte black enameled) | • |
Cooking zone details | |
Number of gas burners | 6 |
1st cooking zone/cooking area | |
Position | front left |
Type | Ultra high-speed burner |
Minimum power output in BTU/hr | 1700 |
Maximum power output in BTU/hr | 19500 |
Max. rating in W | 5700 |
2nd cooking zone/cooking area | |
Position | rear left |
Type | High-speed burner |
Minimum power output in BTU/hr | 1200 |
Maximum power output in BTU/hr | 12500 |
Max. rating in W | 3700 |
3rd cooking zone/cooking area | |
Position | rear right |
Type | High-speed burner |
Minimum power output in BTU/hr | 1700 |
Maximum power output in BTU/hr | 13600 |
Max. rating in W | 4000 |
4th cooking zone/cooking area | |
Position | rear right |
Type | High-speed burner |
Minimum power output in BTU/hr | 1700 |
Maximum power output in BTU/hr | 13600 |
Max. rating in W | 4000 |
5th cooking zone/cooking area | |
Position | front right |
Type | Ultra high-speed burner |
Minimum power output in BTU/hr | 1700 |
Maximum power output in BTU/hr | 19500 |
Max. rating in W | 5700 |
6th cooking zone/cooking area | |
Position | front center |
Type | Ultra high-speed burner |
Minimum power output in BTU/hr | 1700 |
Maximum power output in BTU/hr | 19500 |
Max. rating in W | 5700 |
8th cooking zone/cooking area | |
True Simmer function | • |
User convenience | |
Operation via genuine metal knobs with backlit | • |
Cleaning convenience | |
Dishwasher-safe trivets | • |
Single-piece cooktop surround | • |
Safety | |
Automatic re-ignition | • |
Technical data | |
Dimensions (width) in in. (mm) | 36 (914) |
Dimensions (height) in in. (mm) | 7 5/8 (191) |
Dimensions (depth) in in. (mm) with bullnose | 27 1/4 (692) |
Dimensions (depth) in in. (mm) without bullnose | 25 5/8 (650) |
Weight in lbs. (kg) | 121 (55) |
Total output in BTU/hr | 98200 |
Total connected load in kW | 32.20 |
Voltage in V | 120 |
Fuse rating in A | 10 |
Number of phases | 1 |
Power cord length in in. (m) | 3 (1.2) |
