Overview & Specifications
Overview & Specifications
SAFETY
Safety turn off
FEATURES
Stainless-steel grease filters (10-layer)
Miele CleanCover
Safety turn off
Sensible, even in case of operating errors: The ventilation hood switches off automatically after 10 hours.
FEATURES
Stainless-steel grease filters (10-layer)
Looks great and does a good job: Effective grease filtering and easy cleaning inside the dishwasher.
Miele CleanCover
Protection and easy cleaning: The sealed, smooth surface prevents contact with cables and the motor.
- Safety turn off
- Sensible, even in case of operating errors: The ventilation hood switches off automatically after 10 hours.
- Stainless-steel grease filters (10-layer)
- Looks great and does a good job: Effective grease filtering and easy cleaning inside the dishwasher.
- Miele CleanCover
- Protection and easy cleaning: The sealed, smooth surface prevents contact with cables and the motor.
Design | |
Built-in ventilation hood | • |
Operating modes | |
Recirculated mode | Can be retrofitted |
Recirculation conversion kit (order separately) | DUU 151 |
OdorFree charcoal filter (order separately) | DKFS 31-R DKFS 31-P |
Design | |
Color | Stainless steel |
User convenience | |
Electronic controls | • |
EasySwitch | • |
Operation | EasySwitch |
Cleaning convenience | |
Easy-to-clean CleanCover hood liner | • |
Filter system | |
Number of dishwasher-safe stainless-steel grease filters | 1 |
Lighting | |
LED ClearView lighting | • |
Number x W | 1 x 3,0 W |
Light intensity in Lx | 300 lx |
Color temperature in K | 3500 Kelvin |
Blower | |
Dual-action blower | • |
AC motor | • |
Safety | |
Safety shut-off | • |
Technical data | |
Canopy width in in. (mm) | 35 3/8 (896) |
Canopy height in in. (mm) | 1 1/2 (36) |
Depth of hood canopy in in. (mm) | 10 3/4 (273) |
Minimum distance above electric cooktops in in. (mm) | 24 1/8 (610) |
Minimum height above gas cooktop (max. 12.6 kW total power, burner 4.5 kW) in mm | 26 (660) |
Net weight in lbs. (kg) | 36 (16.0) |
Length of electrical wire in ft. (m) | 2 (0.8) |
Standard plug fitted | • |
Total connected load in kW | 0.35 |
Voltage in V | 120 |
Fuse rating in A | 15 |
Frequency in Hz | 60 |
Number of phases | 1 |
Installation note | |
Vent connection at top | • |
Standard accessories | |
Non-return flap | • |
